Heavy-Duty 25G Hinged Tower Base

For use with guyed or bracketed towers

HEAVY DUTY CARLSON 25G TILTING ANTENNA BASE

click for larger view

Allows your 25G tower to be tilted up and down for easy maintenance.

Unmatched feature set:

  • Same base plate bolt-down pattern as Rohn or American 25G tower
  • The tilt plate is 3/8″ steel – the competition is 1/4″
  • The hinge bolts are 1/2″ – the competition is 3/8″
  • The gussets are 3/8″ instead of 1/4″ or less
  • The mounting pegs are solid, recessed into the tilt plate and welded on both sides
  • The spacing of the 3 tower leg pegs are accurately placed at 11.25″
  • The pegs are 1.060″ in diameter to match the 25G inner diameter of 1.080 with 0.020″ clearance
  • The whole assembly is baked in a zinc thermal diffusion process for ideal corrosion resistance
  • Made in Michigan to accurate tolerances for a smooth and secure fit



Available through DX Engineering
